- Product design and specifications may be changed without prior notice for product improvement.
- Some model(s) is/are not available in the certain country.
- Only the key tags provided by Samsung SDS can be used.
Samsung SDS will not take responsibilities for any problem that may occur because you used an authentication means other than the key tags that we provided.
How to Factory Reset SHS-H505
Model | SHS-H505 |
1 | Unlock and open the door. |
2 |
Press and hold the register button for 5 seconds. You will hear a beep when you first push it, another at 3 seconds, and a third at 5 seconds.
|
3 |
Quickly input on the keypad the master reset code 4560852580* (star key). The keypad will then turn off. 3 beeps will mean the factory default was a success, if you hear 4 consecutive beeps then it failed. If you failed repeat the process until you succeed.
|
4 |
Shut the door and let the door lock automatically lock. The password will be reset to 1234. All saved data will be deleted.
|
Function Table
Accessibilities |
3 Way (Finger Print, Password, Emergency key) |
||
---|---|---|---|
Type |
Lever |
Keypad type |
Touch Pad |
App service |
X |
Status - indicating LEDs |
X |
Welcome function (automatic keypad activation, hovering detection, emergency alarm) |
X |
Randomizer (prevents password from being inferred based on remaining fingerprint) |
O |
Specification
Available Colors
- Silver, Gold
Max User Memory
- 1 Master (PIN) 10 Users (PIN) 100 Fingerprints
Access Mode
- PIN/ Fingerprint Override Key
User Friendly Interface
- No
Double Verification
- PIN + Fingerprint
Auto Card Detection
- No
Intrusion Prevention
- Yes
Out-body Dimension (W x H x D)mm
- 81.3 * 318 * 75
In-body Dimension (W x H x D)mm
- 79 * 290 * 80
Applicable Door Thickness (mm)
- 40 – 80mm
Door to Gate Allowance (mm)
- 90mm
Power
- DC 6V (AA Alkaline batteries) x 8
Battery Life
- Approximately 10 months (Average 10 times per day)
Z-wave Integration Kit
Samsung Wireless Z-wave Integration Kit - Works with Amazon Echo / Google Assistant
