2MP Smoke Detector Covert Camera 4-In-1(TVI/AHD/CVI/CVBS), 1080P, 3.7mm, DC12V
- 4-In-1 (AHD, HD-TVI, HD-CVI, 960H)
- 1/2.7" 2.4MP Aptina Sensor
- Effective Pixels: 1920(H) x 1080(V)
- 3.7mm Fixed Lens
- 0.01Lux @ F1.2 (AGC On)
- 30FPS (NTSC)
- 12V DC
- OSD Menu. Can Switch to Analog Mode
- CoC Compatible (Control Over Coax)
- FLC / BLC (E Model)
- NTSC / PAL Compatible
Output
Max Res.
IP Rating
IR / Range
Power
Note
WDR
TVI
CVI
AHD
960HFixed
3.7mm PinholeN/A
N/A
DC12V
N/A
N/A
CAMERA | |
Image Sensor | 1/3" 2.4MP HD Aptina Sensor |
Effective Pixels | 1920 (H) x 1080 (V) |
Electronic Shutter | AUTO: 1/50-1/100, 000Sec (PAL) & 1/60-1/100,000Sec (NTSC) |
S/N Ratio | ≥48dB |
Video Output | Composite Signal (1.0Vp-p, 75Ω), Compatible with AHD, HD-TVI, HD-CVI, 960H |
Video Frame Rate | 30fps @ 1080P |
CAMERA FEATURES | |
AGC | Automatic / manual |
IR LEDs | N/A |
IR LEDs Distance | N/A |
Day / Night | Auto / Color / BW / EXT |
Noise Reduction | 2D DNR |
BLC | Automatic / manual |
White Balance | Auto adaptive(Range 2200~10000K) |
WDR | N/A |
OSD Menu | via Coaxial Cable (CoC), Compatible with Analog Mode |
LENS | |
Focal Lens | 3.7mm Fixed Lens |
RECORDING | |
Encode | CBR |
GENERAL | |
Power Supply | DC 12V ± 10% |
Power Consumption | 300mA |
Working Environment | -22ºF ~ 140ºF (-30°C ~ 60°C) |
Dimensions | 4.7" x 2.3" x 2.2" (119 x 59 x 56mm) |
Weight | 0.8lbs (0.35kg) |
